Dépôt numérique
RECHERCHER

Green synthesis of novel biocomposites from treated cellulosic fibers and recycled bio-plastic polylactic acid.

Téléchargements

Téléchargements par mois depuis la dernière année

Laadila, Mohamed Amine; Hegde, Krishnamoorthy; Rouissi, Tarek; Brar, Satinder Kaur; Galvez-Cloutier, Rosa; Sorelli, Luca; Cheikh, Ridha Ben; Paiva, Maria et Abokitse, Kofi (2017). Green synthesis of novel biocomposites from treated cellulosic fibers and recycled bio-plastic polylactic acid. Journal of Cleaner Production , vol. 164 . pp. 575-586. DOI: 10.1016/j.jclepro.2017.06.235.

[thumbnail of P003173.pdf]
Prévisualisation
PDF
Disponible sous licence Creative Commons Attribution Non-commercial No Derivatives.

Télécharger (5MB) | Prévisualisation

Résumé

This study investigated mechanical properties of biocomposites developed from recycled polylactic acid (PLA) from packaging industry and treated cellulosic fibers from pulp and paper solid waste. Microwave and enzymatic treatments were used for extraction and surface modification of hydrophilic cellulosic fibers. Enzymatic treatment was specifically performed for activation of hydroxyl groups and improvement of adhesion between matrix and fibers including controlling the length of cellulosic fibers with size reduction of around 50% (142 and 127 μm for primary and mixed biosolids, respectively) as compared to microwave treatment. Microwave treatment produced cellulosic fibers of 293 and 341 μm, for primary and mixed biosolids, respectively. Mechanical properties of biocomposites with 2% (w/w) of treated cellulosic fibers (Young's Modulus 887.83 MPa with tensile strain at breakpoint of 7.22%, tensile stress at yield 41.35 MPa) was enhanced in comparison to the recycled PLA (Young's Modulus 644.47 ± 30.086 MPa with tensile strain at breakpoint of 6.01 ± 0.83%, tensile stress at yield of 29.49 ± 3.64 MPa). Scanning electron microscopy revealed size reduction of cellulosic fibers. X-ray diffraction and Fourier transform infrared spectroscopy confirmed strong mechanical properties of novel biocomposites.

Type de document: Article
Mots-clés libres: biocomposite; cellulosic fiber; microwave treatment; enzymatic treatment; mechanical test; polylactic acid
Centre: Centre Eau Terre Environnement
Date de dépôt: 16 févr. 2018 22:19
Dernière modification: 17 avr. 2020 18:43
URI: https://espace.inrs.ca/id/eprint/6330

Gestion Actions (Identification requise)

Modifier la notice Modifier la notice
